Модем VDSL AC1200 модем гигабитный двухдиапазонный маршрутизатор

Product Specifications

Hardware Parameters

Chipset

RTL8685FB+RTL8812FR+RTL8192FR

CPU frequency

Dual core 1GHz

Memory

128MB DDR

Flash

128MB nand flash

WIFI

2T2R 2.4GHz 802.11b/g/n, 300Mbps

2T2R 5.8GHz 802.11AC, 867Mbps

DSL

Up:60Mbit，Down：100Mbit

WAN

1 x RJ45 10M/100M/1000M

Device Interfaces

4 x RJ45 10M/100M/1000M  LAN Ethernet

1 x reset button

1 x WPS button

1xWIFI ON/OFF button

1 x Power jack

1 x Power switch

2 X RJ11

WIFI Antenna

2 x 5dBi external 2.4G antenna

2 x 5dBi external 5.8G antenna

WIFI Features

Standard

802.11b/g/n/ac

11N: 2.4~2.4835GHz

11AC: 5.150~5.825GHZ

Korea、Japan、ETSI、FCC channels can be selected

Modulation schemes

OFDM = BPSK,QPSK, 16-QAM, 64-QAM 256-QAM

DSSS = DBPSK, DQPSK, CCK

Transfer Rate

HT20: up to 144 Mbps

HT40: up to 300 Mbps

VHT80:  up to 867Mbps

Software Features

General

DSL main Protocols:

= ANSI T1.413 Issue 2

= ITU-T G.992.1 (G.dmt) Annexes A and B

= G.992.2 (G.lite) AnnexesA and B

= G.992.3 ADSL2 (G.dmt.bis) Annexes A, B, I, J, L, and M

= G.992.4 ADSL2 (G.lite.bis)

= G.992.5 ADSL2+

= G.993.1 VDSL

= G.993.2 VDSL2 (35b included)

= G.998.4 G.INP

= G.993.5 G.VECTOR

DSL spec Features:

= ADSL UBR / CBR / rt-VBR / nrt-VBR QoS

= ADSL Bitswap / SRA Capability

= ADSL Auto PVC

= VDSL2 profile 8A / 8B / 8C / 8D / 12A / 12B / 17A / 30A / 35B

Wireless main Protocols:

= IEEE 802.11a

= IEEE 802.11b

= IEEE 802.11g

= IEEE 802.11n

= IEEE 802.11ac

= IEEE 802.11h(dfs)

= IEEE 802.11e(wmm)

Wireless spec Features:

= Embedded AP with 4 SSIDs on each Radio

= Separate authentication for each SSID

= Multicast to Unicast

= AutoChannel

= Wep/ WPA/WPA2/WPA Mixed Security

= WPS

Voice main Protocols:

= RFC3261/3262 (optional)

= RFC2833/4733 (optional)

= RFC4566 (optional)

= RFC3551 (optional)

= RFC2833 (optional)

= RFC2976 (optional)

= RFC4028 (optional)

= RFC3550 (optional)

= RFC3960 (optional)

= RFC5009 (optional)

= RFC4568 (optional)

Voice spec Features:

= VOIP(optional)

= SIP Proxy(optional)

= Codec: G711 / G722 / G726 / G729 (optional)

=  Fax T.38 (optional)

= VAD (Voice Activity Detection) (optional)

= Jitter Buffer Control

= Silence suppression(optional)

= CNG (Comfort Noise Generation) (optional)

= Supports G.168 (echo cancellation) (optional)

Network main Protocols:

= RFC0768 UDP

= RFC0791 IP

= RFC0792 ICMP

= RFC0793 TCP

= RFC0826 Ethernet ARP

= RFC0894 IP over Ethernet

= RFC0922 Broadcasting Internet Datagrams

= RFC0950 Internet Standard Subnetting Procedure

= IEEE802.3 Ether Type

= IEEE802.1p

= RFC2516 PPP Over Ethernet (PPPoE)

= RFC1332 PPP Internet Protocol Control Protocol

= RFC1042 Transmission of IP Datagrams over IEEE 802 Networks

= IPoE

Network spec Features:

= IPv4/IPv6 dual stack

= 6RD / DSLite

= IPoE Bridge Mode

= IPoE DHCP / Static

= PPPoE Dynamic / Static

= IPv6 Stateless / Stateful

= IGMP proxy and MLD for IPTV

= DNS Proxy

= DHCP server

= NAT,NAPT and ALG

Other spec Features:

= QoS

= DMZ and Port forwarding(Virtual server)

= SPI Firewall, Denial of Service (DoS) protection

= MAC / IP / Port filtering

= URL filter

= DDNS

= Static route/RIP

= SNTP

= Diagnostics(Ping / Traceroute / OAM Loopback / DSL Diagnostic / Diag Test)

= Logs and statistics

= Automatic timing restart

Management Features:

= WEB GUI

= Command Tool Telnet For Debug

= TR-069 Remote Management

= UPNP

Environment Requirement

Operating Temperature

0°C~40°C

Storage Temperature

-30°C ~ 70°C

Operating Humidity

5%~95% (typical)

Power Supply

12V/1.5A

EMC/Safety
